Description

Plusrite Cross Arm Bracket for 4 Flood Lights – FLB-200-50-4

The Plusrite FLB-200-50-4 Cross Arm Bracket is a heavy-duty, four-way mounting solution designed to support up to four flood lights on a single pole. Constructed from robust angle steel (100x100x5mm) and rectangular tube (100x50x4mm), this bracket delivers exceptional strength and stability for large-scale commercial and industrial lighting installations.

Quad-mount configuration for maximum coverage

With four 500mm arms extending from a central hub, the FLB-200-50-4 allows you to position four flood lights with optimal spacing for broad, even light distribution. This configuration is ideal for high-mast lighting applications where maximum area coverage is required from a single pole, reducing infrastructure costs while maximising illumination.

Universal 76mm spigot fitting

The bracket features a standard 76mm spigot fitting, making it compatible with the full range of Plusrite LED flood lights, solar flood lights, and area lights. Whether you’re upgrading an existing pole-mounted installation or designing a new lighting layout, the FLB-200-50-4 integrates seamlessly with standard Australian lighting pole infrastructure.

Built for Australian conditions

The galvanised and powder-coated finish provides excellent corrosion resistance, ensuring reliable performance in coastal, industrial, and high-humidity environments. The heavy-gauge steel construction is engineered to handle significant wind loading and the weight of four luminaires, maintaining structural integrity in even the most demanding outdoor conditions.

Applications

• Large car park and commercial precinct lighting
• Sports field and stadium perimeter lighting
• Industrial yard and logistics hub lighting
• High-mast solar flood light installations
• Mining and resource site lighting
• Public space and streetscape lighting upgrades

Specifications

• Model: FLB-200-50-4
• Configuration: 4 flood light mounting points
• Arm length: 500mm each
• Construction: Angle 100x100x5mm / Rectangular Tube 100x50x4mm
• Finish: Galvanised and powder coated
• Spigot: 76mm fitting

Contact Plusrite

For help specifying the right mounting hardware for your lighting project, contact the Plusrite team on (03) 9708 2552 or visit plusrite.com.au.
